TILTING CIRCULAR SAW MACHİNE WORKING VIDEO
PHOTO GALLERY
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS - 3800
Max diameter of outside and of saw
Max cutting depth (90° degree)
Max cutting depth (45 ° degree)
Max. width of cut
Circular Saw (R.P.M.)
Power of saw motor
Table Dimensions
Measure of disc added iron disc
Measure of shield on Table
Measure of wandering sledge
Movement of wandering sledge
Measure of wandering sledge shield
Angle of wandering sledge shield
Carriage dimension
Measure of shield on carriage
Angle of shield on carriage
Dust vacuuming connecting
Inside and outside diameter of stripe saw
Speed of stripe saw (R.P.M.)
Power of stripe saw motor
Net weight
Ø 300 x 30 mm- 400 x 30 mm
Ø 300 - 80 / Ø 400 - 100
60 mm
120
4000x5500 d/dk.
4 Hp
680 x 1000 mm.
630 x 1000 mm
1000 x 1500 mm
380 x 3500 mm
3800 mm
700 x 50 mm
Ø-45° (right and left)
700 x 1800 mm
1500 x 60 mm
Ø-45° (right and left)
120 mm
Ø 125 x Ø 20 mm
6000 d/dk
0.75 HP
890 kg.
TECHNICAL SPECIFICATIONS - 3200
Max diameter of outside and of saw
Max cutting depth (90° degree)
Max cutting depth (45 ° degree)
Max. width of cut
Circular Saw (R.P.M.)
Power of saw motor
Table Dimensions
Measure of disc added iron disc
Measure of shield on Table
Measure of wandering sledge
Movement of wandering sledge
Measure of wandering sledge shield
Angle of wandering sledge shield
Carriage dimension
Measure of shield on carriage
Angle of shield on carriage
Dust vacuuming connecting
Inside and outside diameter of stripe saw
Speed of stripe saw (R.P.M.)
Power of stripe saw motor
Net weight
Ø 300 x 30 mm - 400 x 30 mm
Ø 300 - 80 / Ø 400 - 100
60 mm
120
4000 x 5500 d/dk.
4 Hp
680 x 1000 mm.
630 x 1000 mm
1000 x 1500 mm
380 x 3000 mm
3200 mm
700 x 50 mm
Ø-45° (right and left)
700 x 1800 mm
1500 x 60 mm
Ø-45° (right and left)
120 mm
Ø 125 x Ø 20 mm
6000 d/dk
0.75 HP
820 kg.
TECHNICAL SPECIFICATIONS - 2800
Max diameter of outside and of saw
Max cutting depth (90° degree)
Max cutting depth (45 ° degree)
Max. width of cut
Circular Saw (R.P.M.)
Power of saw motor
Table Dimensions
Measure of disc added iron disc
Measure of shield on Table
Measure of wandering sledge
Movement of wandering sledge
Measure of wandering sledge shield
Angle of wandering sledge shield
Carriage dimension
Measure of shield on carriage
Angle of shield on carriage
Dust vacuuming connecting
Inside and outside diameter of stripe saw
Speed of stripe saw (R.P.M.)
Power of stripe saw motor
Net weight
Ø 300 x 30 mm - 400 x 30 mm
Ø 300 - 80 / Ø 400 - 100
60 mm
120
4000x5500 d/dk.
4 Hp
680 x 1000 mm.
630 x 1000 mm
1000 x 1500 mm
380 x 2500 mm
2800 mm
700 x 50 mm
Ø-45° (right and left)
700 x 1200 mm
1500 x 60 mm
Ø-45° (right and left)
120 mm
Ø 125 x Ø 20 mm
6000 d/dk
0.75 HP
750 kg.
